How to Develop a FHIR IG

FHIR IG (Implementation Guide) is a set of artifacts that describe the requirements for a FHIR server. For example, an IG may contain a set of rules, profiles, extensions, search parameters, and examples of FHIR resources.

The IG is described as an NPM package with the following structure:

package (subfolder) package.json (package manifest)
A set of canonical resource files …

Package Manifest

To start creating IG, we need to describe the package manifest file. A package manifest is a JSON file called package.json.

{
	// The globally unique identifier of the package.
	// A package name consists of two or more namespaces separated by a dot.
	// Each namespace starts with a lowercase alphabet character
	"name": "myorganization.mypackage",

	// The version of the package (SemVer).
	// SHALL contain only letters, numbers, and the characters ".", "_", and "-"
	"version": "1.0.0",

	// The description of the package.
	"description": "My FHIR NPM Package",

	// The author of the package.
	"author": "Author Name",

	// The list of package dependencies.
	// Should contain at least one FHIR core package.
	"dependencies": {
    	  "hl7.fhir.r4.core": "4.0.1",
    	  "hl7.fhir.us.core": "5.0.1"
	}
}

Package Content

A package contains a set of FHIR resources in the JSON format. Let's describe a few resources for the package.

2.1 Profile

Let's describe a profile of the US Core Patient in the file StructureDefinition-my-patient-profile.json.

{
    // Type of the FHIR resource.
    "resourceType": "StructureDefinition",

    // How the type relates to the baseDefinition.
    "derivation": "constraint",

    // Defines the kind of structure that this definition is describing.
    "kind": "resource",

    // Type constrained by this structure.
    "type": "Patient",

    // The status of this structure definition.
    "status": "active",

    // Name for this structure definition (computer friendly).
    "name": "my-patient-profile",

    // 	Whether the structure is abstract.
    "abstract": false,

    //The Canonical identifier for this structure definition is represented as a URI (globally unique).
    "url": "http://custom-url/my-patient-profile",

    // Definition from which this type is constrained.
    "baseDefinition": "http://hl7.org/fhir/us/core/StructureDefinition/us-core-patient",

    "differential": {
        "element": [
            {
                // Element ID
                "id": "Patient.address",

                // Path of the element in the hierarchy of elements
                "path": "Patient.address",

                // The minimum number of times this element SHALL appear in the instance.
                "min": 1
            }
        ]
    }
}

We have described a profile that inherits from the US Core Patient and adds a required field for address.

2.2 SearchParameter resource

Let's describe a custom search parameter on the Patient resource in the file SearchParamete-my-patient-search.json.

{
	// Type of the FHIR resource.
	"resourceType": "SearchParameter",

	// ID of the search parameter.
	"id": "Patient-myname",

	// Canonical identifier for this search parameter, represented as a URI (globally unique).
	"url": "http://hl7.org/fhir/SearchParameter/Patient-myname",

	// Business version of the search parameter.
	"version": "4.0.1",

	// Name for this search parameter (computer friendly).
	"name": "myname",

	// Natural language description of the search parameter.
	"description": "text",

	// The resource type(s) this search parameter applies to.
	"base": ["Patient"],

	// Status of the search parameter.
	"status": "active",

	// Recommended name for the parameter in search url.
	"code": "myname",

	// 	The type of value that a search parameter may contain, and how the content is interpreted.
	"type": "string",

	//FHIRPath expression that extracts the values.
	"expression": "Patient.name"
}

Build NPM package

The resulting npm package has the following structure:

package
├── StructureDefinition-my-patient-profile.json
├── SearchParameter-my-patient-search.json
└── package.json

We need to build the artifacts of the npm package into an archive in the TAR (.tar.gz) format.

tar -czvf package.tar.gz package

Following the guide, upload the archive to Aidbox.
